Coaxial Connector TN02-0058-C06-R - TNC Reverse Polarity Crimp Bulkhead Jack, Nickel Plated, RG58, LBC195, URM43

Browse for other connectors

▣

Product Overview

Part Number

TN02-0058-C06-R

Series

TNC Reverse Polarity

Style

Jack - Bulkhead

Description

TNC Reverse Polarity Crimp Bulkhead Jack, Nickel Plated, RG58, LBC195, URM43

Primary Fixing

Crimp

▣

Specifications

Electrical

Dielectric Withstanding

1500 Volts RMS Maximum

Impedance

50 ohms

Working Voltage

500 Volts RMS Maximum

Environmental

RoHS Compliant

Yes

Temperature Range

-65 to +165 degrees C

Material

Body

Brass, Nickel Plated

Dielectric

PTFE

Ferrule

Brass, Nickel Plated

O Ring

Rubber

Brass, Gold Plated

Mechanical

Cable Retention

Equal to breaking strain of cable

Durability

500 mating cycles

Fixing Method

Crimp

▣

Cable Preparation

A =	8.00mm
B =	6.00mm
C =	3.00mm

▣

Tooling

Crimp Die Sizes

1.69mm hex.

View tooling

5.41mm hex.

▣

Documents

Certificate of Conformance

REACH Policy and Statement

RoHS Certificate of Compliance

▣

Order

UK stock	0
Pending	0
Minimum order quantity	1000

▣

Pricing

1 off	£6.65 each
10 off	£5.31 each
50 off	£4.83 each
100 off	£4.59 each
300 off	£4.37 each

For products with an MOQ, you may order any quantity up to the available online stock. For additional quantities the MOQ will apply.

For assistance please call or email our technical sales team.

▣

Order

UK stock	0
Pending	0
Minimum order quantity	1000

▣

Pricing

1 off	£6.65 each
10 off	£5.31 each
50 off	£4.83 each
100 off	£4.59 each
300 off	£4.37 each

For products with an MOQ, you may order any quantity up to the available online stock. For additional quantities the MOQ will apply.

For assistance please call or email our technical sales team.

▣
