N Type | Jack - Flange | Crimp
Product Overview
Part Number
NT06-3161-C06
Series
Description
N Type Crimp Flange Jack, Integral Contact, Nickel Plated, RG174, LBC100, RG316
Primary Fixing
Specifications
Electrical
Dielectric Withstanding
2500 Volts RMS Maximum
Impedance
50 ohms
Interface Frequency
11 GHz
Working Voltage
1500 Volts RMS Maximum
Environmental
RoHS Compliant
Yes
Temperature Range
-65 to +165 degrees C
Material
Body
Brass, Nickel Plated
Contact
Brass, Gold Plated
Dielectric
PTFE
Ferrule
Brass, Nickel Plated
Integral Pin
Brass, Gold Plated
O Ring
Rubber
Mechanical
Cable Retention
Equal to breaking strain of cable
Durability
500 mating cycles
Fixing Method
Crimp
Cable Preparation
A = 7.50mm
B = 2.50mm
C = 2.50mm
S1_R
Tooling
Crimp Die Sizes
0.72mm sq.
3.25mm hex.
Documents
Order
UK stock 473
Taiwan stock 10
Pending () 115
Minimum order quantity 1
Pricing
1 off £7.79 each
10 off £6.22 each
50 off £5.66 each
100 off £5.38 each
300 off £5.12 each
