SMA | Plug - Right Angle | Solder / Clamp
Browse for other connectors Configure in Cabulator
▣
Product Overview
Part Number
MA17-141K-L04
Series
SMA
Style
Plug - Right Angle
Description
SMA Clamp Right Angle Plug, Stainless Steel, KF141
Primary Fixing
Solder / Clamp
▣
Specifications
Electrical
Dielectric Withstanding
1000 Volts RMS Maximum
Impedance
50 ohms
Insertion Loss
< 0.06 * sqrt (f.GHz) dB
Interface Frequency
18 GHz
VSWR
< 1.35 @ 18 GHz
Working Voltage
500 Volts RMS Maximum
Environmental
RoHS Compliant
Yes
Temperature Range
-65 to +165 degrees C
Material
Body
Passivated Stainless Steel
Dielectric
PTFE
Mechanical
Cable Retention
Equal to breaking strain of cable
Durability
500 mating cycles
Mating Torque
0.79 to 1.13Nm
▣
Documents
Conformance Document
Certificate of Conformance
Compliance Document
REACH Policy and Statement
Compliance Document
RoHS Certificate of Compliance
▣
Order
UK stock 0
Pending 0
Minimum order quantity 1
▣
Pricing
1 off $42.59 each
5 off $34.07 each
10 off $31.23 each
50 off $28.39 each
▣
Order
UK stock 0
Pending 0
Minimum order quantity 1
▣
Pricing
1 off $42.59 each
5 off $34.07 each
10 off $31.23 each
50 off $28.39 each
▣
