Coaxial Connector BN15-1694-C06-Z - BNC 12G SDI Crimp Plug, Nickel Plated, Gigatronix UHD75-6 / 6XF, Belden 4694R

Browse for other connectors

▣

Product Overview

Part Number

BN15-1694-C06-Z

Series

BNC 12G SDI

Style

Plug - Straight

Description

BNC 12G SDI Crimp Plug, Nickel Plated, Gigatronix UHD75-6 / 6XF, Belden 4694R

Primary Fixing

Crimp

▣

Specifications

Electrical

Dielectric Withstanding

1500 Volts RMS Maximum

Impedance

75 ohms

Interface Frequency

12 GHz

Working Voltage

500 Volts RMS Maximum

Environmental

RoHS Compliant

Yes

Temperature Range

-55 to +85 degrees C

Material

Body

Zinc Alloy, Nickel Plated

Coupling Nut

Brass, Nickel Plated

Dielectric

Delrin

Ferrule

Brass, Nickel Plated

Brass, Gold Plated

Mechanical

Cable Retention

Equal to breaking strain of cable

Captive Contact

Yes

Contact Gender

Male

Contact Termination

Crimp

Durability

500 mating cycles

Fixing Method

Crimp

▣

Cable Preparation

A =	7.50mm
B =	3.20mm
C =	4.00mm

▣

Tooling

Crimp Die Sizes

1.07mm sq.

View tooling

7.06mm hex.

▣

Documents

12G SDI 4K Connector Brochure

Certificate of Conformance

REACH Policy and Statement

RoHS Certificate of Compliance

▣

Order

UK stock	0
Pending	0
Minimum order quantity	1000

▣

Pricing

1 off	£2.49 each
10 off	£1.99 each
50 off	£1.81 each
100 off	£1.72 each
300 off	£1.63 each

There is a minimum order quantity for this product.

You may order any quantity up to the available online stock (if any) or any quantity in excess of the MOQ.

For alternative products see listed below. For assistance please call or email our technical sales team.

BN15-1694-C06D-Z

BN15-1694-C06X-Z

BN15-1694-C23-Z

▣
