BNC | Plug - Straight | Crimp
Browse for other connectors Configure in Cabulator
▣
Product Overview
Part Number
BN15-0214-C06
Series
BNC
Style
Plug - Straight
Description
BNC Crimp Plug, Nickel Plated, RG214
Primary Fixing
Crimp
▣
Specifications
Electrical
Dielectric Withstanding
1500 Volts RMS Maximum
Impedance
50 ohms
Interface Frequency
4 GHz
Working Voltage
500 Volts RMS Maximum
Environmental
RoHS Compliant
Yes
Temperature Range
-55 to +85 degrees C
Material
Body
Brass, Nickel Plated
Coupling Nut
Brass, Nickel Plated
Dielectric
Delrin
Ferrule
Brass, Nickel Plated
Pin
Brass, Gold Plated
Mechanical
Cable Retention
Equal to breaking strain of cable
Durability
500 mating cycles
Fixing Method
Crimp
▣
Cable Preparation
A = 9.00mm
B = 0.00mm
C = 4.00mm
S1_R
▣
Tooling
Crimp Die Sizes
2.54mm hex.
View tooling
10.90mm hex.
▣
Documents
Conformance Document
Certificate of Conformance
Compliance Document
REACH Policy and Statement
Compliance Document
RoHS Certificate of Compliance
▣
Order
UK stock 106
Pending 0
Minimum order quantity 1
▣
Pricing
1 off £5.25 each
10 off £4.19 each
50 off £3.81 each
100 off £3.62 each
300 off £3.45 each
▣
Order
UK stock 106
Pending 0
Minimum order quantity 1
▣
Pricing
1 off £5.25 each
10 off £4.19 each
50 off £3.81 each
100 off £3.62 each
300 off £3.45 each
▣
