Products | Coaxial Cable | Part Number: UHD75-179D-500
Part Number
UHD75-179D-500
Description
12G-SDI, 4K, RG179DT Digital Video Cable, 0.3/1.4, supplied on 500 metre drums
Electrical
Recommended Frequency
DC to 12 GHz
Velocity Of Propagation
80%
Environmental
Temperature Range
-20 to +75 degrees C
Material
Centre Conductor
Silver Plated Copper
Dielectric
Physical Foam Polyethylene
Outer Conductor
Bonded Aluminium Foil
Overall Braid
Tinned Copper
Mechanical
Bending Radius Flexing
30mm
Bending Radius Static
8mm
Centre Conductor Diameter
0.31mm
Dielectric Diameter
1.42mm
Outer Conductor 2 Diameter
1.52mm
▣
Competitor Cross Reference
Part Number
Compatibility
| UK stock |
19 |
| Pending |
0 |
| Minimum order quantity |
1 |
Drum length: 500
| 1 off |
£237.59 each |
| 3 off |
£214.22 each |
| 5 off |
£209.35 each |
| 10 off |
£204.48 each |
| 30 off |
£194.82 each |
| UK stock |
19 |
| Pending |
0 |
| Minimum order quantity |
1 |
Drum length: 500
| 1 off |
£237.59 each |
| 3 off |
£214.22 each |
| 5 off |
£209.35 each |
| 10 off |
£204.48 each |
| 30 off |
£194.82 each |
